Innovative digital hydraulics technology, integrating variable-speed electric drives with redesigned system architectures, promises significant energy savings and emission reductions in industrial fluid power applications, offering a pragmatic pathway to decarbonisation alongside electrification.
According to the original report by Alessandro Carmona of Danfoss Power Solutions, digital hydraulics, an approach that couples variable-speed electric drive technology with redesigned pump, actuator and system architectures, can deliver step-change improvements in industrial hydraulic efficiency and a material reduction in CO₂ emissions. Industry analyses cited by Carmona estimate that fluid-power machinery is responsible for roughly 1.8–2.0 Gt of CO₂ per year, with over 40% of that attributable to transmission and hydraulic losses; digital-hydraulics architectures, he argues, can cut energy use substantially and reduce emissions by around one-third while increasing system efficiency by up to 50%.
Why hydraulic systems matter
Electrification delivers clear efficiency advantages in many applications, but fluid power retains technical and commercial relevance where very high power or force density, compactness, robustness and intrinsic safety are required, notably in primary metals, heavy manufacturing, marine/offshore and many mobile off‑highway machines. According to Carmona, for those sectors that will continue to rely on fluid power, the industry must prioritise larger efficiency gains through digitalisation rather than treat electrification as the sole route to decarbonisation.
What “digital hydraulics” means in practice
Carmona distinguishes digital hydraulics from simple VSD retrofits. The digital-hydraulics paradigm pairs a speed-on-demand electric motor (induction or PMSM/servo) with appropriately sized fixed- or variable-displacement pumps, sophisticated P/Q (pressure/flow) control software and, where appropriate, decentralised electrohydraulic actuators (EHAs). Running pumps and motors only as required eliminates the constant bypass/relief flow of conventional systems and can reduce energy consumption dramatically, Carmona cites reductions of up to 70% versus a conventional fixed‑speed baseline depending on duty cycle, and project-level energy savings in field trials have been reported in the 20–25% range for retrofit digital pump solutions.
Technology variants and system trade-offs
- Induction-motor + VSD solutions provide an accessible efficiency uplift for lower‑dynamic applications and are well suited to centralised HPUs.
- Servo‑motor (PMSM) architectures deliver closed‑loop, high‑dynamic control with superior pressure/flow on demand for medium- and high‑control applications.
- Electrohydraulic actuators decentralise hydraulic power for modular machines, reduce system oil volumes and leakage risk, and can replace complex valve manifolds in systems where many functions are electrified.
Practical benefits extend beyond energy: downsizing pumps and motors reduces mass and footprint, lowers cooling requirements and oil volumes, and cuts noise and maintenance costs, factors that shorten payback and accelerate adoption in cost‑sensitive industrial fleets.
Evidence and industry examples
Industry partnerships and research back these claims. Field studies of Danfoss’s digital pump technology (Dextreme) paired with electric drives showed energy reductions in the mid‑20% range in excavator trials, enabling smaller battery packs for electrified off‑highway equipment. Volvo Construction Equipment and Norrhydro have demonstrated multi‑chamber digital actuators (NorrDigi™) for excavators that reduce hydraulic subsystem complexity and fuel/CO₂ consumption, with production intent announced for machine integration. Independent modelling and experimental work on hydraulic hybrid drivetrains indicates that replacing conventional pumps and motors with digital counterparts can raise drivetrain efficiency from typical 64–81% ranges toward nearly 90% in some simulated duty cycles, implying up to ~25% improvement in overall transmission efficiency in those cases.
Implementing change: skills, standards and collaboration
Carmona stresses that realising the potential of digital hydraulics requires competence upgrades across component suppliers, OEMs and end users, plus stronger collaboration between industry and academia. European initiatives convening industry, universities, trade associations and CETOP to develop a coordinated technology roadmap are cited as a model for accelerating disruptive developments and easing technology transfer into production machines.
What this means for industrial decarbonisation decisions
For B2B decision‑makers in industrial decarbonisation, the message is pragmatic: assess system‑level emissions and duty cycles before defaulting to electrification. Where fluid power remains the best technical fit, redesigning hydraulic power and control for “power on demand” can unlock large reductions in energy use, operational CO₂ and total cost of ownership. Pilot projects and component-level trials, covering digital pumps, servo drives and EHAs, are the recommended next step to validate duty‑cycle benefits and quantify whole‑system impacts (including footprint, oil volume, noise and maintenance) in the user’s operating context.
According to the original report, combining these technologies with coordinated R&D and standards work offers a credible pathway to deliver competitive, lower‑emission fluid‑power machines now, while electrification progresses where technically and economically appropriate.
