As global chip manufacturing expands rapidly, industry leaders emphasise the need for innovative methods to reduce water and energy use, integrating circularity and efficiency to ensure supply chain resilience and environmental sustainability.
Semiconductor manufacturing’s rapid advance is colliding with hard limits in energy and water resources, forcing fabs and equipment suppliers to reframe production priorities around conservation, reuse and operational efficiency. Ryan Zrno, chief executive of JST, argues that addressing water and energy demands in wet processing and cleanroom systems is now central to sustaining both output and supply‑chain resilience.
Water is the industry’s most conspicuous constraint. The sector already consumes volumes comparable to a major city, S&P Global estimated chipmakers use as much water as Hong Kong, and ultrapure water demands are acute because rinsing and contamination control tolerate no compromise. Industry analysis from Deloitte notes the sector’s huge process dependence on water, with most usage tied to manufacture, and highlights that recycling rates vary widely but can be high: some Taiwanese operations average roughly 85% reuse. NIST guidance for CHIPS‑funded projects underscores the same priorities, reduce, recycle and treat process wastewater wherever feasible, and pursue dry alternatives to wet steps where possible.
JST reports it has cut water use by around 50% through changes in wet bench design, single‑wafer processing, tighter chemical control and sensor‑driven automation, and it is targeting a 75% reduction over time. According to the company, single‑wafer benches and lower chemical concentrations not only shrink rinse volumes but also simplify neutralisation and reintegration of effluents into deionised water systems. JST also points to smaller tool footprints, robotics and improved flow sequencing as levers to reduce per‑wafer water consumption while raising throughput.
Those device‑level and tool‑level measures sit alongside broader plant‑scale interventions. TSMC has rolled out an EUV Dynamic Energy Saving Programme that, the company says, cut peak power usage of some EUV scanners by 44% in pilot fabs and is expected to deliver hundreds of millions of kilowatt‑hours in savings by 2030 through adaptive power scaling and idle‑state management. Separately, TSMC is constructing a large industrial reclamation water plant in Phoenix to convert process wastewater into ultrapure water for its Arizona fabs, reflecting a shift toward near‑closed‑loop water systems at major foundries.
Energy and water efficiency are intertwined. JST highlights lower tool exhaust requirements, more efficient heat‑exchange and inverter motor control as ways to reduce cleanroom conditioning loads, improvements that, in turn, ease demand on chilled water and HVAC systems, a significant component of fab energy use. Deloitte’s forecasting analysis also identifies abatement systems and cooling as material water sinks and notes that placing certain scrubbers or abatement units into idle when not processing can cut water for abatement by nearly all of its current draw.
The scale and pace of capacity expansion globally add urgency. Reports indicate China is planning a dramatic ramp in advanced node wafer‑starts to feed domestic AI and compute demand, a push that, if realised, will multiply regional water and power needs even as export controls limit access to some high‑end tools. Rapid growth in advanced manufacturing, whether in Taiwan, the United States or China, magnifies the imperative for equipment and fab designs that are both water‑lean and energy‑efficient.
Operational longevity and circularity in equipment also matter for decarbonisation and resource efficiency. JST stresses modular platforms that extend tool service life and permit incremental upgrades rather than wholesale replacements, reducing embodied emissions and the waste associated with frequent capital turnover. Such approaches can improve return on investment for fab operators while aligning with corporate sustainability targets.
Regulatory and financing pressures are reinforcing these technical trends. Government programmes tied to the CHIPS Act explicitly encourage reduced freshwater demand, improved ultra‑pure water production efficiency and onsite reuse; energy providers and regulators are increasingly offering incentives and rebates for demonstrable efficiency gains, according to JST and industry observers. Meanwhile, corporate buyers and insurers are attentive to water‑risk metrics, an issue flagged in S&P Global work that links water stress to credit‑risk considerations for semiconductor facilities.
For industrial decarbonisation professionals advising fabs and OEMs, the immediate priorities are clear: quantify process‑level water footprints, target single‑wafer and dry‑process substitutions where feasible, deploy sensing and adaptive control to eliminate idle energy and water flows, and design systems for reuse and long asset lives. Achieving the next step change in sustainability will require equipment vendors, fab operators, utilities and regulators to align incentives so low‑water, low‑energy process configurations become the default rather than the exception.
The technological and policy levers now exist to materially reduce the sector’s environmental footprint, but delivering that at the scale of global chip manufacturing will demand coordinated implementation, capital commitment and a willingness to redesign long‑standing wet processes around reuse and efficiency rather than throughput alone.
